IOSiX ELD

GPSTab ELD is registered & compliant with FMCSA.
IOSiX’s device is the smallest form factor in the industry.

Availability: In stock

$199.00

About the Product

The IoSix ELD with GPSTab is a no-contract, FMCSA approved system designed to help your fleet drive more miles and make more money.

In combination with our monthly GPSTab app, your fleet can implement the HOS flexibility in alignment with FMCSA regulations. The hardware connects directly to the J1939 port and is compatible with virtually all ELD systems. The connector comes in various versions to support your needs, firmware options are available to suit your needs.

GPSTab ELD is registered & compliant with FMCSA.

IOSiX’s device is the smallest form factor in the industry.

  • Wi-Fi

    802.11bgn WiFi interface with embedded antenna

  • Bluetooth

    Bluetooth 4.2 Low Energy interface with embedded antenna

  • GPS Antenna

    66-channel high-performance/sensitivity GPS receiver with embedded antenna

  • Processor

    Dual-core 240MHz processor

  • Flash Memory

    2MB flash memory, good for more than 30 days of ELD data buffering

  • CAN Bus

    Up to 3x CAN bus interfaces allow access to all vehicle data 1x J1708 interface

  • Interfaces

    OEM-grade and certified vehicle interfaces shared with other IOSiX products

  • Protocols

    Support for J1939, ISO-15765, J1587, and other vehicle protocols for maximum compatibility

  • Corrections

    Contains over 100 field-identified corrections to vehicle information

  • Update

    Firmware easily updatable over-the-air

  • Voltage

    Operates from 4-30V, can withstand -30 to +100V

  • Temperature

    Industrial -40 to +125 C operational temperature range

  • Certification

    FCC and IC certified

  • Weight

    28 g

  • Dimensions

    40.3 × 40.3 × 28.3 mm
